Vinyl-Insulated Bullet disconnector MPD

Product Details

Cable size:0.5~1.5mm²(A.W.G.22~16) Max current:Imax=10A Material: brass Item No. Thickness of material Dimension(mm) Color (mm

Product Parameters

Vinyl-Insulated Bullet disconnector MPD

Cable size:0.5~1.5mm²(A.W.G.22~16)   Max current:Imax=10A   Material: brass

Item No. Thickness of material Dimension(mm) Color
(mm) F H L
MPD1.25-156 0.4 4.0 10.6 1.7 10.6 21.2 Red

Cable size:1.5~2.5mm²(A.W.G.16~14)   Max current:Imax=15A   Material: brass

Item No. Thickness of material Dimension(mm) Color
(mm) F H L
MPD2-156 0.4 4.0 10.6 2.3 12.6 21.2 Blue
MPD2-195 0.4 5.0 10.6 2.3 10 21.2

Cable size:4~6mm²(A.W.G.12~10)   Max current:Imax=24A   Material: brass

Item No. Thickness of material Dimension(mm) Color
(mm) F H L
MPD5.5-195 0.4 5.0 12 3.4 13.5 25.5 Yellow
